Description
The 24V 200A Car Start Relay is designed for high current applications in 24V systems. It is suitable for various uses such as starter control, trunk unlocking, and central locking systems.
- Product Type: Relay
- Compatibility: 24V systems
- Material: Plastic
- Key Feature: High current capacity (200A)
- Contact Material: AgSnO12
- Contact Form: Normally open
- Contact Ratings: 200A at 14/28VDC
- Contact Resistance: 100mΩ max at 6V DC 1A
- Max Switching Current: 500A (5 ms)
- Max Switching Voltage: 75VDC
- Max Switching Power: 2000W
- Expected Lifespan (Electric): 100,000 operations (at 30 operations/min)
- Mechanical Life: 10,000,000 operations
- Coil Rated Voltage: 24VDC
- Coil Resistance: 120Ω
- Operate Voltage Max: 12 ~ 16.8VDC
- Release Voltage: 2.4 ~ 7.2VDC
- Overload Voltage Max: 31.2VDC
- Temperature Range: -30 ~ +80°C
- Vibration Resistance: 10 ~ 55Hz, 1.5mm
- Impact Resistance: Operation extreme: 10g, damage limits: 100g
- Humidity: 40% ~ 85%
- Insulation Resistance: 100 MΩ min at 500 VDC
- Dielectric Strength: 500VAC (between open contacts for one minute)
- Dielectric Strength: 750VAC (between contact and coil for one minute)
- Operating Time: 7ms
- Release Time: 5ms
