Bluetooth 4.0 Dual Mode Mini Scanner Car Code Readers Diagnostic Tool OBD 2 OBDII ELM327 Protocols
Bluetooth 4.0 Dual Mode Mini Scanner Car Code Readers Diagnostic Tool OBD 2 OBDII ELM327 Protocols
Spread the cost
Mobicred is a third-party credit option. Approval and terms are determined by Mobicred.
- Approval by Mobicred
- Rate & fees in your pre-agreement
- Repayments confirmed before acceptance
- Your interest rate, fees and repayment schedule are shown in Mobicred's pre-agreement.
- Approval and your credit limit are determined by Mobicred.
- Review the credit terms before accepting the agreement.
Available payment options are confirmed at checkout.
Continue to checkoutDon't have Mobicred yet? Visit Mobicred →
Credit is subject to Mobicred approval and terms. Your limit, interest rate, fees and repayment schedule are disclosed by Mobicred before acceptance. Mobicred terms and conditions
Duties & Import Tax Information
In Stock
Processing: 1–3 days
Couldn't load pickup availability
Product details
Description
The Bluetooth 4.0 Dual Mode Mini Scanner is a diagnostic tool for OBD-II compliant vehicles. It enables users to read and clear diagnostic trouble codes, providing real-time sensor data for vehicle maintenance.
- Product Type: Code Readers & Scan Tools
- Compatibility: OBD-II compliant vehicles
- Key Feature: Wireless Bluetooth connectivity
- Software Version: V2.1 (depending on software)
- Hardware Version: V1.5
- Supported Operating Platforms: iOS, Android, Symbian, Windows
- Supported Protocols:
- SAE J1850 PWM (41.6Kbaud)
- SAE J1850 VPW (10.4Kbaud)
- ISO9141-2 (5 baud init, 10.4 Kbaud)
- ISO14230-4 KWP (5 baud init, 10.4 Kbaud)
- ISO14230-4 KWP (fast init, 10.4 Kbaud)
- ISO15765-4 CAN (11bit ID, 500 Kbaud)
- ISO15765-4 CAN (29bit ID, 500 Kbaud)
- ISO15765-4 CAN (11bit ID, 250 Kbaud)
- ISO15765-4 CAN (29bit ID, 250 Kbaud)
- Functions:
- Read diagnostic trouble codes, both generic and manufacturer-specific
- Clear trouble codes and turn off the MIL (Check Engine light)
- Display current sensor data including:
- Engine RPM
- Calculated Load Value
- Coolant Temperature
- Fuel System Status
- Vehicle Speed
- Short Term Fuel Trim
- Long Term Fuel Trim
- Intake Manifold Pressure
- Timing Advance
- Intake Air Temperature
- Air Flow Rate
- Absolute Throttle Position
- Oxygen sensor voltages / associated short term fuel trims
- Fuel System status
- Fuel Pressure
- Communication: Bluetooth 4.0
- Master Chip: ST
- Working Voltage: 9V-16V
- Working Current: 35mA
- Standby Current: 25mA
- Operating Temperature: -40~85 degrees Celsius
- Working Humidity: less than 60%
- Size: 43mm x 25mm x 30mm
